GSDU
/ Surface
Coming Soon
Key Features
Energy-Saving Design
- World-class pump efficiency achieved.
- Stainless Steel AISI 316 (CF8M) Impeller designed using our proprietary 3D inverse design technology.
- Higher efficiency means lower energy consumption and motor output, and more compact size.
Easy Installation and Simple Maintenance
- Alignment is not required with close coupled design.
- Internally epoxy coated A48 CLS35 cast iron casing with back pull-out design enables disassembly and inspection without removal of suction and discharge piping.
- Shaft seal flushing and quenching piping not required for standard applications.
- Air bleeding is not required.
- Simplified shaft seal and o-ring casing seals enable easy assembly.
- Dry shaft design prevents corrosion on motor shaft.
Type: End Suction / Surface
Market: Municipal Clean Water / Commercial / Industrial
Specifications
- Discharge Size : 1 1/4″ to 6″
- Power Range: 1 1/2 to 50 hp
- Capacity: to 2000 GPM (60Hz)
- Head: to 460 ft (60Hz)
- Liquid temperature range: 14° F to 250° F
- Maximum working pressure: up to 200 psi
- ANSI B16.1 125lb flanges
DOCUMENTATION & DOWNLOADS
APPLICATIONS
- Water Supply
- Drainage
- Irrigation
- Air Conditioning
- Cooling Services
- General Industries
- Transfer Pump
- Booster Pump
